Aircraft
Takeoff Weight
< 249 g
Standard aircraft weight (including the Intelligent Flight Battery and a microSD card). Actual product weight may vary due to differences in batch materials and other factors. Training or examination is not required for flying this product in most countries and regions. Always check local laws and regulations before use. Always check and strictly abide by local laws and regulations before flying.
Dimensions
Folded: 136×62×165 mm (L×W×H)
Unfolded: 233×280×79 mm (L×W×H)
Max Ascent Speed
5 m/s (Sport mode)
5 m/s (Normal mode)
2 m/s (Cine mode)
Max Descent Speed
5 m/s (Sport mode)
5 m/s (Normal mode)
1.5 m/s (Cine mode)
Max Horizontal Speed
At sea level, in windless conditions:
12 m/s* (Sport mode)
12 m/s (tracking status)
At sea level, with 4 m/s tailwind, while flying in the same direction as the wind:
16 m/s* (Sport mode)
12 m/s (tracking status)
* Measured in a wind tunnel test environment with the aircraft taking off from an altitude of 0 m and ascending vertically by 1.5 m in Sport mode. Data is for reference only. Always pay attention to reminders on the camera view during your flight.
Max Takeoff Altitude
3000 m
In a windless environment, a fully charged aircraft can take off from an altitude of 3000 m, ascend vertically by 500 m, and fly in Sport mode until the battery level drops to 20%. Data is for reference only. Always pay attention to reminders on the camera view during your flight.
Max Flight Time
31 minutes
Measured when flying forward at a constant speed of 6 m/s in a windless environment 20 m above sea level, in photo mode, and from 100% battery level until 0%. Actual experience may vary depending on the environment, usage, and firmware version.
Max Hovering Time
28 minutes
Measured when hovering in a windless environment 20 m above sea level, in photo mode, and from 100% battery level until 0%. Actual experience may vary depending on the environment, usage, and firmware version.
Max Flight Distance
14 km
Measured when flying forward at a constant speed of 9 m/s in a windless environment 20 m above sea level, in photo mode, and from 100% battery level until 0%. Actual experience may vary depending on the environment, usage, and firmware version.
Max Wind Speed Resistance
10.7 m/s (Level 5)
Operating Temperature
-10° to 40° C (14° to 104° F)
Global Navigation Satellite System
GPS + Galileo + BeiDou
Internal Storage
2 GB
Class
C0 (EU)
Camera
Image Sensor
1/1.3-inch image sensor
Lens
FOV: 82.1°
Format Equivalent: 24 mm
Aperture: f/1.7
Focus: 1 m to ∞
ISO Range
Video
Normal/Slow Motion:
100-6400 (Normal)
100-1600 (D-Log M)
12MP Photo: 100-6400
48MP Photo: 100-3200
Shutter Speed
12MP Photo: 1/16000-2 s (2.5-8 s for simulated long exposure)
48MP Photo: 1/8000-2 s
Max Image Size
48MP Photo
8064×6048
Still Photography Modes
Single Shot: 12 MP and 48 MP
Burst Shooting:
12 MP, 3/5/7 frames Automatic Exposure Bracketing (AEB):
12 MP, 3/5/7 frames at 2/3 EV step
Timed:
12 MP, 2/3/5/7/10/15/20/30/60 s
Photo Format
JPEG
DNG/RAW
Video Resolution
4K: 3840×2160@24/25/30/48/50/60/100fps
FHD: 1920×1080@24/25/30/48/50/60/100fps
2.7K Vertical Shooting: 1512×2688@24/25/30fps
FHD Vertical Shooting: 1080×1920@24/25/30fps
Video Format
MP4
Max Video Bitrate
150Mbps
Supported File System
exFAT
Color Mode
Normal
D-Log M
Digital Zoom
4K: 3x
FHD: 4x
2.7K Vertical Shooting: 3x
FHD Vertical Shooting: 4x
12 MP Photo: 3x
Gimbal
Stabilization
3-axis mechanical gimbal (tilt, roll, pan)
Mechanical Range
Tilt Axis: -130° to +63°
Roll Axis: -47° to +47°
Pan: -30° to +30°
Controllable Range
Tilt Axis: -90° to +35°
Max Control Speed (tilt)
100°/s
Angular Vibration Range
±0.01°
Sensing
Sensing Type
Downward: one visual sensor and an infrared sensor, Forward: 3D Infrared Sensing System
Forward
3D Infrared Sensing System
Measurement Range: 0.3-8 m (reflectivity > 10%)
FOV: Horizontal 60°, Vertical 60°
Downward
Measurement Range: 0.3-8 m (reflectivity > 10%)
Precise Hovering Range: 0.5-10 m
FOV: Horizontal 60°, Vertical 60°
Operating Environment
Downward:
Surfaces with discernible patterns, diffuse reflectivity > 20% (such as cement pavement), and adequate lighting (lux > 15)
Video Transmission
Video Transmission System
O4
Live View Quality
Remote Controller:
Up to 1080p/60fps
Operating Frequency
2.4000-2.4835 GHz
5.170-5.250 GHz
5.725-5.850 GHz
Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.
Transmitter Power (EIRP)
2.4 GHz:
<30 dBm (FCC)
<20 dBm (CE/SRRC/MIC)
5.1 GHz:
<23 dBm (CE)
5.8 GHz:
<33 dBm (FCC)
<14 dBm (CE)
<30 dBm (SRRC)
Max Transmission Distance (unobstructed, free of interference)
FCC: 13 km
CE: 8 km
SRRC: 8 km
MIC: 8 km
Measured in an open, outdoor environment without interference or obstructions and represents the farthest communication range under each standard. The actual max transmission distance during flight is limited by the drone's max flight distance. Always pay attention to RTH reminders on the camera view during your flight.
Max Transmission Distance (unobstructed, with interference)
Strong Interference (urban landscape): Approx. 1-2.5 km
Medium Interference (suburban landscape): Approx. 2.5-7 km
Low Interference (suburb/seaside): Approx. 7-13 km
Measured under FCC standard in unobstructed environments with typical interference. Used for reference purposes only and provides no guarantee for actual transmission distance.
Max Transmission Distance (obstructed, with interference)
Low Interference and Obstructed by Buildings: Approx. 0-0.5 km
Low Interference and Obstructed by Trees: Approx. 0.5-2 km
Measured under FCC standard in obstructed environments with typical low interference. Used for reference purposes only and provides no guarantee for actual transmission distance.
Max Download Speed
O4:
DJI RC-N3 Remote Controller: 10 MB/s
DJI RC: 10 MB/s
Wi-Fi 5: 30 MB/s
Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz. Download speeds may vary depending on the actual conditions.
Lowest Latency
Approx. 120 ms
Depending on the actual environment and mobile device.
Antenna
4 antennas (2.4 GHz: 1T2R; 5.2/5.8 GHz: 2T2R)
Wi-Fi
Protocol
802.11a/b/g/n/ac
Operating Frequency
2.4000 GHz-2.4835 GHz
5.7250 GHz-5.850 GHz
Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.
Transmitter Power (EIRP)
2.4 GHz：
<20 dBm（FCC/CE/SRRC/MIC）
5.8 GHz：
<20 dBm（FCC/SRRC）
<14 dBm （CE）
Effective Operating Range
50 m
Measured in an open environment free of interference. Actual transmission distance may vary by the operating environment.
Bluetooth
Protocol
Bluetooth 5.0
Operating Frequency
2.4000-2.4835 GHz
Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.
Transmitter Power (EIRP)
＜10 dBm
Battery
Capacity
3110 mAh
Weight
Approx. 83.5 g
Nominal Voltage
7.16 V
Battery Type
Li-ion
Chemical System
LiNiMnCoO2
Energy
22.3 Wh
Charging Temperature
5° to 40° C (41° to 104° F)
Charging Time
When Charging via Aircraft (30W max charging power):
From 0% to 100%: Approx. 70 minutes*
When Using the Battery Charging Hub for Charging One Battery (48W max charging power):
From 0% to 100%: Approx. 45 minutes**
When Using the Battery Charging Hub for Parallel Charging Two Batteries (65W max charging power):
Two batteries from 0% to 100%: Approx. 70 minutes***
* Using the DJI 30W USB-C Charger or a charger that supports the PD protocol with a power output higher than 30 W.
** Using the DJI 65W USB-C Charger or a charger that supports the PD protocol with a power output higher than 48 W.
*** Using the DJI 65W USB-C Charger or a charger that supports the PD protocol with a power output higher than 65 W.
Battery Charging Hub
Input
5 V, 4.3 A
9 V, 4.3 A
12 V, 4.3 A
15 V, 4.3 A
Output (power accumulation)
Max 45 W
Output (charging)
15 V, 2 A
12 V, 2 A
9 V, 3 A
5 V, 3 A
Rated Power
65 W
Charging Type
2 batteries charged simultaneously or in sequence
Compatibility
DJI Flip Intelligent Flight Battery
Charger
Recommended Charger
DJI 65W Portable Charger*
USB Power Delivery chargers
* When you charge the battery mounted to the aircraft, the maximum charging power supported is 30 W.
* When you charge the battery inserted into the Parallel Charging Hub, the maximum charging power supported is 65 W.
Storage
Recommended microSD Cards
Kingston CANVAS Go! Plus 64GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 128GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 256GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 512GB U3 A2 V30 microSDXC
Lexar Professional 1066x 64GB U3 A2 V30 microSDXC
Lexar Professional 1066x 128GB U3 A2 V30 microSDXC
Lexar Professional 1066x 256GB U3 A2 V30 microSDXC
Lexar Professional 1066x 512GB U3 A2 V30 microSDXC
DJI RC-N3 Remote Controller
Max Operating Time
Without Charging Any Mobile Device: 3.5 hours
When Charging a Mobile Device: 1.5 hours
Operating Temperature
-10° to 40° C (14° to 104° F)
Max Supported Mobile Device Size
180×86×10 mm (L×W×H)
App
Mobile Device App
DJI Fly
Required Operating System
iOS 13.0 or later
Android 7.0 or later
